Front linkage

FPS-JD 2036R / 2038R / 2032R

#maytheforcebewithyouFull power ahead

The matev FPS-JD 2036R front power lift delivers an impressively stable design and sophisticated construction.

Since the very beginning, every matev front power lift has been optimally adapted to the relevant tractor design, thus guaranteeing maximum fitting accuracy as well as easy assembly. The tried-and-tested lifting geometry of our front power lifts ensures the greatest lifting height possible in a compact design and enables reliable operation up to the tractor's performance limits, even in the most difficult applications. Our front power lifts are optimally adapted for use with the attachments from the matev product range, which makes them a universal implement for a wide range of applications. Optimal dimensioning of lifting power over the lift height always enables fast and trouble-free attachment and detachment of implements.

Facts & Figures

Downloads
Attachment option
2032R
2036R
2028R
Extension sets
Cat. 0
Cat. 1 Walterscheid arrestor hook
ScanFrame
Weight
50 kg
Lifting force at the coupling point
1,500 kg
Lifting force 600 mm before the coupling point
600 kg
Number of cylinders
2
Removable lower link
Front PTO shaft
opt.
Live PTO shaft
-
Hydraulic extension set
opt.
